SolarMax Solon Dual Series 6KW Off-Grid Inverter

Description

SolarMax Solon Dual Series 6KW Off-Grid Inverter

The SolarMax Solon Dual Series 6KW is a versatile off-grid inverter designed to work with or without a 48V battery. It features advanced MPPT technology, dual AC outputs for different load types, and built-in WiFi for remote monitoring. This inverter offers reliability, ease of use, and efficient power conversion for residential and small commercial applications.

A reliable and efficient hybrid solar inverter designed for residential and small commercial systems. Featuring advanced energy management capabilities, this inverter ensures optimal performance and long-term durability. Key Features Pure Sine Wave Output: Provides clean and stable power suitable for sensitive devices. Wide PV Input Voltage Range: Operates within a voltage range of 60VDC ~ 400VDC, compatible with various solar panels. Maximum PV Input: Handles up to 4,000W of solar power input for efficient energy conversion. Battery Independent Design: Can operate without a battery, offering a cost-effective solution for users who don’t need energy storage. Battery Equalization Function: Optimizes battery performance and extends battery life by balancing cell voltage. Maximum Charging Current: Supports up to 100A for fast and efficient battery charging. Durable Design: Built-in anti-dust kit ensures reliable performance in harsh environments. Maximum AC Output: Delivers up to 3,000W of AC power, suitable for standard household and small commercial applications. BMS Communication Port: Reserved communication port for Battery Management System (BMS) integration. The PRIMAX GALAXY PV4000+ is an ideal solution for those seeking reliable, cost-effective, and efficient solar power systems with or without energy storage. RATED POWER 3000VA/3000W INPUT Voltage 230VAC Selectable Voltage Range 170¬280VAC (For Personal Computers) ; 90¬280VAC (For Home Appliances) Frequency Range 50Hz/60Hz(Auto Sensing) OUTPUT AC Voltage Regulation (Batt. Mode) 230VAC+-5% Surge Power 6000VA Efficiency (Peak) 93% Transfer Time 10ms (For Personal Computers) 20ms (For Home Appliances) Waveform Pure Sine Wave BATTERY Battery Voltage 24V DC Floating Charge Voltage 27V DC Overcharge Protection 32V DC SOLAR CHARGER & AC CHARGER Solar Charger Type MPPT Maximum PV Array Open Circuit Voltage 450V DC Maximum PV Array Power 4000W MPPT Range@ Operating Voltage 60¬400VDC Maximum Solar Charge Current 100A Maximum AC Charge Current 800A Maximum Charge Current 100A PHYSICAL Dimension D*W*H(mm) Net Weight (Kgs) 110*288*390 7.2 Communication Interface RS232/RS485 OPERATING ENVIRONMENT Humidity 0% to 90% Relative Humidity (Non-Condensing) Operating Temperature -10¬50C Storage Temperature -15¬60C Related Products

Key Features

• Rated Power: 6000W, suitable for both normal and heavy load applications.
• AC Input Voltage: 230V AC, with selectable voltage ranges of 170-280 VAC (for personal computers) and 90-280 VAC (for home appliances).
• Frequency Range: 50Hz/60Hz (auto sensing) to match local grid requirements.
• Surge Power: 12,000 VA, ideal for handling power surges during startup.
• Pure Sine Wave: Ensures stable, clean power output for sensitive electronics.
• AC Voltage Regulation (Battery Mode): 230V AC ± 5% for stable output.
• Dual AC Output: 6000W total, supporting both main load and smart load.
• Battery Voltage: 48V DC, providing robust energy storage.
• Battery Protection:
  • Floating Charge Voltage: 54V DC
  • Overcharge Protection: 61V DC
  • Low Voltage Cutoff: 42V-49V range
  • High Voltage Range Selectable: 50V-60V
  • SOC Display: Displays battery state in percentage and voltage.
• Works Without Battery: The inverter can operate without a battery, providing flexibility for systems that are not battery-dependent.
• Solar MPPT Charge Controller:
  • Maximum PV Array Open Circuit Voltage: 500V DC
  • Maximum PV Array Power: 6000W+
  • MPPT Range: 60V-450V DC
  • Maximum Charge Current: 120A
  • Maximum PV Input Current: 27A
  • Maximum Efficiency: 98% for optimal energy conversion.
• Communication Interface: Built-in WiFi for remote monitoring and RS485 for BMS (Battery Management System) compatibility with lithium batteries.
• Display: LCD screen for easy monitoring of system status and settings.
• Operating Environment:
  • Humidity: 5% to 90% (non-condensing)
  • Operating Temperature: -10°C to 50°C
  • Storage Temperature: -15°C to 60°C
• Physical Dimensions: 125mm x 340mm x 420mm, weighing 9kg for compact and lightweight installation.
• RGB Lights: For status indication, making it easy to monitor inverter health and operation at a glance.
• Warranty: 2-year parts replacement warranty for peace of mind.

The SolarMax Solon Dual Series 6KW off-grid inverter is designed to offer efficient power conversion and reliable performance for both normal and heavy load applications. Its MPPT charge controller, dual AC outputs, and ability to function without a battery make it a flexible choice for various energy needs. The built-in WiFi and LCD display provide ease of monitoring and configuration, while the two-year warranty ensures long-term satisfaction with the product.

Note : (Two Year parts replacement warranty)
